| DONANIM ÖZELLİKLERİ | |
|---|---|
| Arabirim | • 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+) • AUTO Negotiation • AUTO MDI/MDIX |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Sayısı | Fanless |
| Fiziksel Güvenlik Kilidi | Yes |
| Harici Güç Kaynağı | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
| Paket Yönlendirme Hızı | 0.8928 Mpps |
| PoE Portları (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 67 W |
| MAC Adres Tablosu | 2K |
| Jumbo Frame | 2 KB |
| Switching Kapasitesi | 1.2 Gbps |
| Boyutlar ( W X D X H ) | 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm) |
| Maks. Güç Tüketimi | • 2.52 W (220 V / 50 Hz, no PD connected) • 75.4 W (220 V / 50 Hz, with 67 W PD connected) |
| Max Heat Dissipation | • 8.59 BTU/h(no PD connected) • 257.11 BTU/h(with 67 W PD connected) |
| YAZILIM ÖZELLİKLERİ | |
|---|---|
| İletim Metodu | Store-And-Forward |
| Gelişmiş Fonksiyonlar | • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode: Ports 1–4 • Priority Mode: Ports 1–2 • PoE Auto Recovery: Ports 1-4 • Mac Address Auto-Learning and Auto-Aging • IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode |
| DİĞERLERİ | |
|---|---|
| Sertifika | FCC, CE, RoHS |
| Paket İçeriği | • DS106P • Power Adapter • Installation Guide |
| Ortam | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
